Light and Sound Bluetooth Controller for DeAgostini Millennium Falcon

Light and Sound Bluetooth Controller for DeAgostini Millennium Falcon

  • $295.00


Please allow 2 weeks for your order if this item to be processed.


This controller is designed to replace the stock controller provided with DeAgostini Millennium Falcon and enhance the model with additional features. The controller can also work with any other Studio Scale Millennium Falcon or comparable in size (1/43 scale). It allows you to light up and remotely control the engine, landing lights, warning lights, headlights, cockpit, gun ports, internal devices, and do some additional light effects. The engine light effects are accompanied by the sound effects of a working engine. Once the desired light settings have been set using the potentiometers, the controller can be operated remotely with a Bluetooth-enabled device such as a cell phone or a tablet.

The highlights of the controller:

  • Remotely operate light and sound effects of the individual components of the ship using Bluetooth
  • Up to 58 super-bright LEDs in the engine strip for an unprecedented level of brightness
  • 56 LEDs in the cockpit circuit board for realistic light effects*
  • 16 LEDs for the landing lights circuit*
  • 8 Red LEDs for the warning lights circuit*
  • Compatible with DeAgostini boarding ramp
  • Compatible with DeAgostini power and battery box connectors
  • Compatible with DeAgostini headlights and landing lights
  • Ability to customize audio effects by uploading your own audio files
  • Protection from a higher than nominal voltage
  • Protection from reversed polarity

* Available separately

The set comes with the following:

  • The controller
  • Low-frequency audio speaker
  • 24 or 58 LED Engine light strip with adhesive backing
  • 2 LED Fiber optic couplers
  • 6V 3A Universal (110-240v) power supply
  • Power cable

Light and Sound Controller for DeAgostini Millennium Falcon

The controller is built on a custom-designed board to match the mounting holes for the stock board.

The board carries Adafruit Feather M0 - Bluetooth enabled Arduino compatible board built on ARM Cortex processor, Sound FX board, and an amplifier.

Light and Sound Controller for DeAgostini Millennium Falcon

Shown below is the location of the connectors for the stock LEDs and devices as well as the additional ones.

Light and Sound Controller for DeAgostini Millennium Falcon

The controller uses the existing power connections for DeAgostini Millennium Falcon. Although the stock battery box or power supply can be used, it is recommended to use the supplied power adapter.

The soundboard can be removed from its socket and connected through a micro-USB cable to a computer to upload custom audio files. It is also possible to install a different soundboard with higher memory size.

The engine light strip consists of up to 58 super-bright RGB LEDs - the highest density of the LEDs available. The strip is applied to the existing placeholders for the stock strips. The ridge between the placeholders may need to be sanded down.

The color and the light effect of the engines can be adjusted by rotating the first two potentiometers located at the bottom left side of the board. The other two potentiometers set the color of the light coming out of the LED fiber optic couplers and the speed of the light effects of the cockpit LED board.

The LED fiber optic couplers are used for various light effects on the gun ports, interior devices such as communication panels. Each coupler has 4 LEDs, the color of which can be adjusted by turning the third potentiometer.

Light and Sound Controller for DeAgostini Millennium Falcon

The couplers come pre-assembled (The fiber optic strands are not provided):

Light and Sound Controller for DeAgostini Millennium Falcon



Light and Sound Controller for DeAgostini Millennium Falcon

The device is controlled remotely by the free software Adafruit Bluefruit LE Connect available on Apple App Store and Google Play. The installation is simple and straightforward.

Adafruit Bluefruit LE Connect


Separately available add-ons:

Cockpit RGB LED Board Set

The cockpit LED board is an upgrade for the Cockpit Replacement Set released earlier and is installed in the modified back insert for the cockpit cone that comes with it. The board carries 56 nano RGB LEDs that measure just 2mm by 2mm in size and are individually operated by the controller. Please note, this board will not fit into the stock cockpit without major modifications to it.

The set comes with the following parts:

  • The circuit board with 56 nano RGB LEDs
  • Light-blocking isolator
  • Modified clear insert
  • A cable for the connection to the controller

Light and Sound Controller for DeAgostini Millennium Falcon

https://www.falcon3dparts.com/collections/deagostini-millennium-falcon-upgrades/products/complete-cockpit-replacement-set-for-deagostini-millennium-falcon-v-2

Landing Lights Set

A set of 16 LED lights with light holders. It is available as a kit or a fully assembled set. The kit version comes with the following components:

  • 16 Bright white 9000K LEDs 5mm diam.
  • 16 LED holders
  • 16 100Ohm resistors
  • Red and black heat-shrink tube
  • Two-conductor wire
  • Power connector

A view of the fully assembled version:

Light and Sound Controller for DeAgostini Millennium Falcon

 Light and Sound Controller for DeAgostini Millennium Falcon

Warning Lights Set

A set of 8 RED LED lights with 2mm diam at the tip. It is available as a kit or a fully assembled set. The kit version comes with the following components:

  • 8 RED LED lights with 2mm diam at the tip
  • 8 100Ohm resistors
  • Red and black heat-shrink tube
  • Two-conductor wire
  • Power connector

A view of the fully assembled version:

Light and Sound Controller for DeAgostini Millennium Falcon

 Miniature Cable Holders

Keep your wiring tidy with this set of 10 miniature plastic cable holders with self-adhesive backing. The base measures 10mm X 10mm.

Light and Sound Controller for DeAgostini Millennium Falcon

The ability to add and remove additional wires at a later time allows for easy cable management.

Light and Sound Controller for DeAgostini Millennium Falcon
